Nruab nrab voltage marine transformer

CSCD nruab nrab voltage voltage voline transformer yog hom tshwj xeeb ntawm qhuav - hom transformer siv hauv cov av marine. Nws tso siab rau huab cua convection rau cua txias thiab tsis siv cov roj insulating. Nws muaj cov txiaj ntsig zoo li kev nyab xeeb hnyav, kev kho cov nplaim taws me me, cov nplaim taws zoo tshaj plaws, thiab muaj zog kub dissipation thiab noo noo tsis kam. Vim tias qee qhov chaw muaj kev nyab xeeb thiab kev nyab xeeb ntawm cov nkoj, nws cov hluav taws, tawg, thiab noo noo tsis tau tshwj xeeb. Nws tuaj yeem tiv thaiv cov chaw hnyav ntawm cov nkoj hnyav, xws li kev co, cov tshuaj ntsuam ntsev, thiab cov pwm, thiab yog qhov tseem ceeb hauv nkoj lub tshuab.

Qhov nruab nrab hluav taws xob marine transformer siv tau cov khoom lag luam epoxy tshwj xeeb, thiab txij nkawm {{free "qhuav} hom" qauv. Nws lub ntsiab tseem ceeb muaj xws li:

1. Siab - voltage winding (6KV)
Cua winding no yog tsim kev siv epoxy Resin Nqus Plua Plav Casting Technasting Technume. Cov cua tshuab yog qhov txhab nrog siab - rsin resin sib xyaw ua ke hauv lub siab khov kho, uas kho tau los ua tus phom sij, chav tsev. Cov qauv no kiag li cais lub siab- voltage welling, muab tsis tau zoo rau noo noo, thiab roj mist, ua tiav} kev ua haujlwm dawb.

2. Tsawg - voltage winding (0.4kv)

Nws siv cov ntawv txheej tseem ceeb nrog Epoxy Resin kawg - seing thiab kho ntawm qis kawg. Lub siab - winding tam sim no ntawm qhov qis - voltage sab yog qhov txhab los ntawm ib daim ntawv ci los yog tooj liab. Cov ntawv ci - Hom winding muab cov chaw siab, thiab cov kab ke muaj zog {{}} Circuit Court tam sim no.

Tom qab epoxy resin kawg - kev co thiab xoob ua kom muaj zog thiab txo qis thaum lub sijhawm ua haujlwm, kom ua haujlwm ntev}}}}}}} term ua hauj lwm ruaj khov.

3. Cov qauv qauv

Cov tub ntxhais ua haujlwm siab tsim ntawm high - zoo, high {{1} - {}}} {} { Cov qauv no txo ​​qis cov tub ntxhais tsis muaj {{5} butting poob thiab tsis muaj suab nrov thiab muaj zog txuag. Cov nto tseem ceeb yog kho nrog cov txheej txheem tshwj xeeb rau xeb thiab corrosion tsis kam. Cov clamps thiab fasteners yauv tiv thaiv xeb, kom lawv muaj xeb {{}} {}} av noo marine chaw. Cov tub ntxhais thiab cov wurings tau nrawm ua ke rau hauv cov khoom, ua ke chav, muab cov tshuab ntsuas tshwj xeeb.

1. Zoo heev "triple -} Ua pov thawj" lub peev xwm
Lub Epoxy Resin - Chaw Window windings Daim ntawv ntom nti, tiv taus dej hiav txwv, ua kom muaj acidic thiab alkaline roj av, thiab ua kom zoo nkauj ua rau muaj pa taws kev loj hlob. Nrog kev tiv thaiv kev tiv thaiv nce mus txog li IP00 thiab IP20 (nws tuaj yeem tiv thaiv qhov kub thiab txias, nws tuaj yeem tiv thaiv qhov kub thiab txias, siab dua, thiab cov salinity siab nyob rau hauv lub nkoj lub cav chav.


2. Kev co thiab poob siab tsis kam
Tag nrho cov cuab yeej (windings thiab cov tub ntxhais) tau sib txuas ua ke rau hauv cov qauv nruj, nruj} Lub zog, muab cov tshuab siv zog tshwj xeeb. Cov khoom tsim tau txiav txim siab kev co thiab muaj kev cuam tshuam zoo (xws li cua thiab nthwv dej) tsim tawm thaum lub nkoj ua haujlwm. Nws tau dhau txoj kev co nruj thiab cuam tshuam tiv thaiv kev ua kom pom tseeb thiab pub dawb ntawm kev tshee thiab kev cuam tshuam, kom muaj kev nyab xeeb thiab txhim khu kev qha.


3. Ib puag ncig tus phooj ywg thiab txij nkawm - dawb
Cov pa phem - Dawb: Tsis muaj roj, tshem tawm cov kev pheej hmoo ntawm toast, thiab tsis muaj kev pheej hmoo ntawm kev ua qias tuaj rau cov tub rog marine.
Tsawg lub suab: high {- Cov khoom zoo tseem ceeb thiab cov suab sib xyaw ua kom zoo dua li cov khoom lag luam zoo sib xws, txhim kho kev ua haujlwm thiab chaw nyob ua haujlwm.
Txij Nkawm Inne ...-} PUB DAWB: Tag nrho cov kev tsim kho kom muaj kev soj ntsuam sab hauv, txo tus nqi kho thiab ua haujlwm thiab cov khoom lag luam thiab khoom siv peev.


4. Kev siv tshuaj thiab hloov tau yooj yim
CSCD Marine Transformers yog qhov tsim nyog rau cov ntawv thov nrog cov chaw pom zoo, xws li cov nkoj thiab cov pob hluav taws xob thiab tua pov tseg. Tsim los rau kev ua haujlwm siab, ruaj khov, thiab kev nyab xeeb thaum lub sij hawm lub nkoj ua haujlwm, lawv tau tsim los kom wr tau nyob hauv cov dej num hauv tsev marine. Cov Qauv Siv Siv
Iec60076-1, iec60076-2, iec60076-3, IEC60076-5, iEC60076-11, thiab lwm yam.

1. Qauv: CSCD, CSCBD
2. Nyob twj ywm muaj peev xwm: 315-6300 kva
3. Thawj voltage: 6, 6.3, 6.6 kv
4. Thib ob voltage: 0.4, 0.45 kv
5. Zaus: 50 Hz lossis 60 Hz
6. Rwb thaiv chav kawm: F lossis h
7. Cov txheej txheem txias: AF / AF
8. Kev sib txuas pawg: Dyn11, yyn0
9. Kev tiv thaiv chav kawm: IP22, IP23, IP55, lossis raws li tus neeg siv cov cai

1. Qhov siab: tsawg dua los yog sib npaug rau 1000 m
2. Ofist kub:
Qhov siab kawg: +45 degree
Yam tsawg kawg: -25 degree
Qhov nruab nrab txhua hli kub kub: +30 degree
3. Kev ua haujlwm: sab hauv lub nkoj lub tsev
4. Tus txheeb ze cov av noo: tsawg dua los yog sib npaug rau 95%

Marine fais fab faib cov txheej txheem ntawm 1kV thiab hauv qab no.
